Sliding Gate Logistics White Industrial Canopy Shelter Outside Storage Tent
The 15x85m outdoor logistics warehouse storage tent is built for a logistics transporation company as an upgrade of their existing simple iron structure warehousing space. The customer is mainly engaged in the transportation and warehouse storage of bulk materials. In order to keep the lowest operating cost, they used to take cheap simple iron structure as their outdoor warehouse for storage in transit. Unfortunately, after a very short time of use, the iron warehouse got rusty and water leakage occured at many places from time to time.
Please contact with us directly to learn about the detailed specification of different tent projects, because the data in the form may not be updated in time.
| Tent Size: | 15m x 85m | Tent Materials: | Hard extruded aluminum alloy (framework) |
| Span Width: | 15m | | Polyester textile fabric cover (top and wall) |
| Side Height: | 4m | | Galvanized steel (connecting parts) |
| Top Height: | 6.4m | Tent Configurations: | Aluminum framework |
| Bay Distance: | 5m | | Fabric cover 850gsm |
| Longest Part: | 7.9m | | Sliding Gate (Corrugated Sheet Steel) |
| Roof Pitch: | 18° | | Ventilation Louver |
| Main Profile: | 166 x 88 x 3mm | | Rain Canopy |
| Gable Post Profile: | 166 x 88 x 3mm | Setup Time: | 8 people 2 to 3 days |
| Purlin Profile: | 60 x 60 x 2mm | Tent Packaging: | Membrane film for long aluminum parts |
| Hang Tube Profile: | 100 x 80 x 2mm | | PVC bags for fabric parts |
| Snow Load: | 0.15kN/m² | | Steel cages for steel parts |
| Wind Load: | 0.5kN/m² | Tent Fixing Solution: | Expansion screws for concrete ground (standard) |
| Tent Gross Weight: | 8093kgs | | Steel peg nails for soft grass/sand land (optional) |
| Tent Total Volume: | 24cbm | | Load Plate for undamagable ground (optional) |
| Number of Purlin: | 64pcs | Installation Support: | Installation instructional manual & video |
| Tent HS code: | 6306220090 | | On-site installation guide |
| Tent Lifespan: | Aluminum part ≥ 25~30 years | | Factory installation training |
| | PVC fabri ≥ 5~8years | Free Tools Configured: | Y-pole, Spanner, Ropes, Hammers, Ladders |
The durable aluminum logistics storage tent is made up of hard pressed aluminum alloy framework and double pvc-coated polyester textile fabric cover. The maintenance free structural grade aluminum frame in itself has a very elegant outlook. In terms of service life, the aluminum tent frame can be used for more than 15 years, and the durable PVC fabric can be used for 3~5 years.
The temporary storage space aluminum tent frame is fast covered by white PVC canopy, 850 gram per square meter, 0.6mm thick. The PVC warehouse tent canopy is UV resistant, and flame retardant, which can be used in weather temperature ranging from -30° to +70°
Clearspan aluminum frame warehouse tents are more and more widely used in logistics industry. Most goods don't have much strict requirements on warehouse facilities and warehouse equipments. Just like this storage tent project, the core demand of the customer is to provide a temporary shelter space to protect the goods outdoors from sun and rain, at a low cost in a short time!
Normally, to facilitate the industrial tent warehouse installation, the construction site needs to clean up in advance.
Have you found out the limits of your current industrial storage? Why not invest in the storage marquees which can deal with your bulk goods?
