Aluminum Alloy Frame Outdoor Exhibition Tents with Hard Wall and Electric Shutter Door

Name: Aluminum Alloy Frame Outdoor Exhibition Tents with Hard Wall and Electric Shutter Door
Brand: Yashang
Price: 1 USD

Aluminum Alloy Frame Outdoor Exhibition Tents with Hard Wall and Electric Shutter Door Manufactures

Brand Name : Yashang

Model Number : ET40

Certification : ISO, CE, TUV, COC, SONCAP etc.

Place of Origin : China

MOQ : negotiable

Price : negotiable

Payment Terms : T/T, L/C, West Union, MoneyGram

Supply Ability : 5000~10000sqm per month

Packaging Details : membrane film, PVC bags, steel cages

Delivery Time : 25 work days

Frame : Hard Aluminum Alloy Skeleton

Cover : 850gsm Anti-UV PVC Fabric

Connector : Hot Dipped Galvanized Steel

Wall : PVC Fabric, Soft Material

Tent Width : 10m

Application : Outdoor Exhibition and Events

Contact Now

Aluminum Alloy Frame Outdoor Exhibition Tents with Hard Wall and Electric Shutter Door

The tent structure is made of rustless aluminum alloy frame and white double layer PVC coated polyester fabric roof cover. The aluminum alloy profile is significant in the size series. For the width of this tent structure is only 10m, we use the 84 series aluminum alloy. If the width is longer than 10m, for example 12m, the 122 series aluminum alloy should be applied for this size of tent structures. That is to say, the longer the tent width is, the larger the aluminum alloy size is applied.

Please contact with us directly to learn about the detailed specification of different tent projects, because the data in the form may not be updated in time.

Tent Shape:	A-frame shape	Tent Materials:	Hard extruded aluminum alloy (framework)
Span Width:	10m		Polyester textile fabric cover (top and wall)
Side Height:	2.6m		Galvanized steel (connecting parts)
Top Height:	4.4m	Tent Configurations:	Aluminum framework
Bay Distance:	3m		Fabric roof cover
Longest Part:	5.4m		Hard plate wall
Roof Pitch:	20°		Energy-saving lighting system
Main Profile:	84 x48 x 3mm		Decorative lining system
Gable Post Profile:	84 x48 x 3mm		Glass door with canopy
Purlin Profile:	40 x 40 x 2mm	Tent Packaging:	Membrane film for long aluminum parts
Hang Tube Profile:	40 x 56 x 2mm		PVC bags for fabric parts
Snow Load:	0.1kN/m²		Steel cages for steel parts
Wind Load:	0.3kN/m²	Tent Fixing Solution:	Expansion screws for concrete ground (standard)
Tent Gross Weight:	TBC		Steel peg nails for soft grass/sand land (optional)
Tent Total Volume:	TBC		Load Plate for undamagable ground (optional)
Setup Time:	8 people 2 to 3 days	Installation Support:	Installation instructional manual & video
Tent HS code:	6306220090		On-site installation guide
Tent Lifespan:	Aluminum part ≥ 25~30 years		Factory installation training
	PVC fabri ≥ 5~8years	Free Tools Configured:	Y-pole, Spanner, Ropes, Hammers, Ladders

These aluminum alloy frame tents are set up on Shenzhen Convention and Exhibition Center for the exhibition events. The roof pvc fabric color is white with grey. The wall is not PVC fabric wall but sandwich wall which is more sturdy and durable than the fabric wall.

Aluminum Alloy Frame Outdoor Exhibition Tents with Hard Wall and Electric Shutter Door

The rolling shutter door is applied in this tent project.

Aluminum Alloy Frame Outdoor Exhibition Tents with Hard Wall and Electric Shutter Door

Once you subscribe our premium aluminum tents, you will receive high-class products, considerable service and efficient after-sales service.
