Clear Span Windproof 10x18m Outdoor Exhibition Tents Stable and Reliable
This is a 10m wide and 18m long outdoor event tent without gable and side walls. The tent structure consists of rustless aluminum alloy frame and white double layer PVC coated polyester fabric roof cover. The aluminum alloy profile is significant in the size series. For the width of this tent structure is only 10m, we use the 84 series aluminum alloy. If the width is longer than 10m, for example 12m, the 122 series aluminum alloy should be applied for this size of tent structures. The longer the tent width is, the larger of the aluminum alloy size is applied.
Please contact with us directly to learn about the detailed specification of different tent projects, because the data in the form may not be updated in time.
| Tent Size: | 10m x 18m | Tent Materials: | Hard extruded aluminum alloy (framework) |
| Span Width: | 10m | | Polyester textile fabric cover (top and wall) |
| Side Height: | 2.6m | | Galvanized steel (connecting parts) |
| Top Height: | 4.4m | Tent Configurations: | Aluminum framework |
| Bay Distance: | 3m | | Fabric roof cover |
| Longest Part: | 5.4m | | Fabric wall |
| Roof Pitch: | 20° | | Glass door with canopy |
| Main Profile: | 84 x 48 x 3mm | | Decorative lining system |
| Gable Post Profile: | 84 x 48 x 3mm | | Energy-saving lighting system |
| Purlin Profile: | 40 x 40 x 2mm | Tent Packaging: | Membrane film for long aluminum parts |
| Hang Tube Profile: | 40 x 56 x 2mm | | PVC bags for fabric parts |
| Snow Load: | 0.1kN/m² | | Steel cages for steel parts |
| Wind Load: | 0.3kN/m² | Tent Fixing Solution: | Expansion screws for concrete ground (standard) |
| Tent Gross Weight: | 1060kgs | | Steel peg nails for soft grass/sand land (optional) |
| Tent Total Volume: | 3cbm | | Load Plate for undamagable ground (optional) |
| Setup Time: | 8 people 0.5~1 day | Installation Support: | Installation instructional manual & video |
| Tent HS code: | 6306220090 | | On-site installation guide |
| Tent Lifespan: | Aluminum part ≥ 25~30 years | | Factory installation training |
| | PVC fabri ≥ 5~8years | Free Tools Configured: | Y-pole, Spanner, Ropes, Hammers, Ladders |
The clear span aluminum for outdoor exhibition A-frame tent is composed of hard extruded aluminum alloy framework and polyester textile fabric roof and triangle textile, connected by stainless galvanized steel. The A-frame structure with no fabric walls enables the inner space to be more spacious. With the help of cross bridging of the side wall and the plate load, the structure is more stable and reliable.
The weight load plates are applied in this exhibition tent project. On the downtown, the ground always can not be damaged, so only the weight load plates can be fixed into the ground for this tent.
Drawing on more than 12 years' rich experience and great expertise in designing and manufacturing aluminum tents, Yashang tents are made in China with quality performance materials. We always deserve your trust and your generous orders.
