High Wind Load Outdoor Event Tent Structure White PVC Fabirc Cover
Clearspan sectional frame tents (Clearspan Marquees) are used in a wide variety of different applications. Being modular and rigid they can be put up without the need for tensioning guy ropes and cover a range of sizes from 10m x 39m to a 10m span x indefinite length. The outdoor tent structure with high wind load is for events, because it can withstand the wind load as high as 0.3kN/m².
Please contact with us directly to learn about the detailed specification of different tent projects, because the data in the form may not be updated in time.
| Tent Size: | 10m x 39m | Tent Materials: | Hard extruded aluminum alloy (framework) |
| Span Width: | 10m | | Polyester textile fabric cover (top and wall) |
| Side Height: | 2.6m | | Galvanized steel (connecting parts) |
| Top Height: | 4.4m | Tent Configurations: | Aluminum framework |
| Bay Distance: | 3m | | Fabric roof cover |
| Longest Part: | 5.4m | | Transparent glass wall |
| Roof Pitch: | 20° | | Glass door with canopy |
| Main Profile: | 84 x 48 x 3mm | | Decorative lining system |
| Gable Post Profile: | 84 x 48 x 3mm | | Energy-saving lighting system |
| Purlin Profile: | 40 x 56 x 2mm | Tent Packaging: | Membrane film for long aluminum parts |
| Hang Tube Profile: | 40 x 40 x 2mm | | PVC bags for fabric parts |
| Snow Load: | 0.1kN/m² | | Steel cages for steel parts |
| Wind Load: | 0.3kN/m² | Tent Fixing Solution: | Expansion screws for concrete ground (standard) |
| Tent Gross Weight: | 2050kgs | | Steel peg nails for soft grass/sand land (optional) |
| Tent Total Volume: | 5.9cbm | | Load Plate for undamagable ground (optional) |
| Setup Time: | 8 people 1~2 days | Installation Support: | Installation instructional manual & video |
| Tent HS code: | 6306220090 | | On-site installation guide |
| Tent Lifespan: | Aluminum part ≥ 25~30 years | | Factory installation training |
| | PVC fabri ≥ 5~8years | Free Tools Configured: | Y-pole, Spanner, Ropes, Hammers, Ladders |
To prevent from ultraviolet rays and severe weather, the enclosure is covered in white polyester texile fabrics. Besides, the side walls are designed into curtains, which on one hand, the curtains can be drawn back to keep the inside privacy when required, on the other hand, the curtains can be drawn aside to enlarge and brighten the interior space.
With the convenience to erect up and dismantle tents, the temporary tents for outdoor events are popular with customers who want to customize their event venue. For a better perfomance of stability and reliability of the tent, the tent is fixed into the ground with alternative methods. In this project, we fix the expansion screws into the ground. There exist two other methods: load plate with weight loads for the ground that can't be damaged; steel peg nails for soft sand or grass land. It's up to you to choose the fixed method according to your ground condition.
Drawing on more than 12 years' rich experience and great expertise in designing and manufacturing marquees, Yashang Tents are made in China with quality performance materials.
We always deserve your trust and your smart purchase order! Contact us now to know more about tent glass wall...
